11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer

Brand Name: TSTY
Model Number: S11
Price: $1,100.00/units 1-1 units
Detail Information
Product Description
Detail Information
Place of Origin:
Henan, China
Certification:
ISO9001
Use:
Power
Phase:
Three
Coil Structure:
TOROIDAL
Coil Number:
2
Product Name:
Three Phase Transformer
Type:
Oil-filled Transformer
Frequency:
50/60Hz
Material:
Copper / Aluminium
Standard:
IEC / GB
Transformer Type:
S11 Oil-immersed Transformer
Vector Group:
Dyn11 / Yyn0
Warranty:
2 Years
Package:
Wooden Case
Product Description
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 0
Products Description

S13 Electric Oil Immersed Power Transformer

Product Description:

The S13 type is developed by our company on the basis of S11 distribution transformers through the research and application of new materials and new processes, and the combination of independent innovation and technology introduction. Through the optimized and innovative design of the core and coil structure, the goal of reducing no-load loss and noise is achieved. Compared with the current national standard JB/T10088-2004, the noise level has dropped by an average of 20%.

Product Features:

1.The transformer core is laminated with imported cold-rolled silicon steel sheets, which greatly reduces the no-load loss and no-load current.
2.High and low voltage windings are made of oxygen-free copper, and low voltage windings adopt double-layer cylindrical structure. high voltage winding adopts multilayer cylindrical structure. 1000kVA and above can adopt foil winding. The product has strong short-circuit resistance.
3.The transformer connection group uses Dyn11 to reduce the impact of harmonics on the power grid and improve the quality of power supply. 4.The transformer is a fully sealed structure, which prolongs the service life
5.The measured noise value is lower than the standard.
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 1
Technical Parameter for S13 Transformer
Rated Capacity
(KVA）
Connection group label
High voltage
(kv)
Tap range
(kv)
Low voltage
(kv)
No-load loss & current (%)
Load loss
Dy * Yy
Short circuit resistance
（%）
10



















Yyn0 or Dyn11



















10       6.3
 6
















±5% ±2X2.5%or +3X2.5%-1X2.5%


















0.4
40*2.8
360*340











4.0
20
70*2.5
525*500
30
80*2.3
630*600
50
100*2.0
910*870
63
110*1.9
1090*1040
80
130*1.9
1310*1250
100
150*1.8
1580*1500
125
170*1.7
1890*1800
160
200*1.6
2310*2200
200
240*1.5
2730*2600
250
290*1.4
3200*3050
315
340*1.4
3830*3650
400
410*1.3
4520*4300
500
480*1.2
5410*5150






4.5
630
570*1.1
6200*6200
800
700*1.0
7500*7500
1000
830*1.0
10300*10300
1250
970*0.9
12000*12000
1600
1170*0.8
14500*14500
2000
1510*0.8
17800*17800
2500
1780*0.7
20700*20700

5.0
3150
2100*0.7
24300*24300
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 2
Oil type transformer structure diagram
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 3

Product Standard:

GB/T 1094 Power Transformer GB/T 15164 Oil-immersed Power Transformer Load Guide GB/T 6451 Three-phase Oil-immersed Power Transformer Technical Parameters and Requirements IEC/60076
Applicable Environment:
1.The altitude does not exceed 1000m. We can also customize according to your demand. 2.Maximum temperature: +40℃ 3.Average temperature of the hottest month: +30℃ 4.Minimum temperature: -10℃ (outdoor) 5.Maximum daily temperature difference: 25K 6.Ice thickness: 10mm 7.Monthly average maximum relative humidity (25℃): 90% 8.Installation location: outdoor
Product packaging
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 4
Transformer Case
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 5
Company Profile
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 6
TSTY Electric Co., Ltd. was established in 2007 and is an excellent and reliable transformer manufacturer in China. The company mainly develops and produces oil-immersed transformers, dry-type transformers, box-type substations and high and low voltage complete sets of equipment.
The equipment put into production and operation of the project advocates energy saving, intelligence, information and mechanization. The company has established the Henan Triangle Energy-saving Transformer Engineering Technology Research Center, with 71 utility model patents and 15 invention patents.
With years of accumulation in the transformer industry and strong technological innovation capabilities, it provides comprehensive solutions for the Chinese power industry. The company is a key procurement unit for large-scale national projects such as State Grid, State Railway Administration, Zhengzhou Coal Group, Pingmei Group and South-to-North Water Diversion.
VR
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 7
Certifications
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 8
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 9
1.Our company provides you with project design and process design, and designs and manufactures products according to your equipment purchase plan and specific needs. And train technical and operating personnel for you.
2.The newly purchased products are provided with online assistance for installation and debugging. The products are under the lifelong service system. If problems occur in normal use, we will provide solutions within one working day after receiving user's feedback. We will try our best to get the product up and running as soon as possible. And there are regular visits by professional technicians to ensure the long-term, safe and reliable use of our products.
3.We use quality authentic materials, process and manufacture in strict compliance with ISO9001:2000 international quality management to ensure the quality of excellence and the smooth installation!
Factory Display
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 10
Trade show
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 11
Customer Visiting
11/6.6kV 11kV 1500kVA 2000kVA Three Phase Oil Immersed Transformer 2 MVA Transformer 12
FAQ
Q：what's your major products? A: oil immersed transformer, dry type transformer, Transformer Substation, High and Low Voltage Switchgear Q: Can your product be customerized? A: Considering differences in voltage, frequency and other speciality of transformer product in different countries and regions,our product can be customerized according to your requirements. Q: When can I get the price? A:Usually we quote within 24 hours after we get your inquiry. Q: What about lead or shipping time? A: The lead time depends on the quantity you ordered, generally within 15 days upon receipt of advance payment. Q: What is the price of shipping? A: Depending upon the port of delivery, prices varies. Q: Do you offer guarantee for the products? A: Yes. We offer at least one years guarantee for all of our transformers.
