Oil-filled Transformer S11 11kv/415v 3 Phase 35kv/3.3kv 6.6kv Wooden Case TSTY
All Category

Oil Immersed Transformer

Dry Type Transformer

Transformer Substation

High And Low Voltage Switchgear

Single Phase Transformer

Liquid Cooled Energy Storage Cabinet

Top Sale
Contact Us
Mr. Wang
info@tstyelectric.com
15803834403
Contact Now
Oil-filled Transformer S11 11kv/415v 3 Phase 35kv/3.3kv 6.6kv Wooden Case TSTY
  • name
  • name
  • name
  • name
  • name
  • name

Oil-filled Transformer S11 11kv/415v 3 Phase 35kv/3.3kv 6.6kv Wooden Case TSTY

Brand Name: TSTY
Model Number: S11
Price: $980.00/units 1-1 units
Detail Information
Product Description
Detail Information
Place of Origin:
Henan, China
Certification:
ISO9001
Use:
Power
Phase:
Three
Coil Structure:
TOROIDAL
Coil Number:
2
Product Name:
Oil Cooled Transformer
Type:
Oil-filled Transformer
Frequency:
50/60Hz
Material:
Copper / Aluminium
Standard:
IEC / GB
Transformer Type:
S11 Oil-immersed Transformer
Vector Group:
Dyn11 / Yyn0
Warranty:
2 Years
Package:
Wooden Case
Product Description
Products Description
Oil Cooled Transformers S11 11kv/415v 3 Phase 35kv/3.3kv 6.6kv Transform 35kv Power TOROIDAL Copper / Aluminium Wooden Case TSTY
* This model is produced in accordance with Chinese national GB standards and the international IEC standards.
* It uses oil as the main insulation means of the transformer, and relies on oil as the cooling medium, such as oil-immersed natural cooling, oil-immersed air cooling, etc.
* Widely used in chemical plants, factories, remote places and other harsh environments.
Oil-filled Transformer S11 11kv/415v 3 Phase 35kv/3.3kv 6.6kv Wooden Case TSTY 0
Oil Cooled Transformer Features:
The S11 series fully sealed oil-immersed power transformer developed and produced by the company has the advantages of low loss, low noise and high efficiency, which can achieve good energy-saving effects and reduce pollution.
The transformer is isolated from the air to prevent and slow down the deterioration of oil and insulation aging so as to enhance operational reliability, and maintain normal operation without maintenance.
1.The transformer core is laminated with imported cold-rolled silicon steel sheets, which greatly reduces the no-load loss and no-load current. The core is bound to ensure the tightness of the core and reduce noise.
2.High and low voltage windings are made of oxygen-free copper, and low voltage windings of 500kVA and below adopt double-layer cylindrical structure. 630kVA and above adopt double helix or four helix structure, high voltage winding adopts multilayer cylindrical structure. 1000kVA and above can adopt foil winding.
3.The transformer connection group uses Dyn11 to reduce the impact of harmonics on the power grid and improve the quality of power supply.
4.The transformer is a fully sealed structure, which prolongs the service life, does not require hanging cores and maintenance.
5.The measured noise value is lower than the standard. After this series of transformers have been transported normally, the relevant parts can be installed without core inspection, and they can be put into operation once the acceptance test is qualified.
6.The terminal box can be used for oil transformers above 2000kva, which can reduce on-site installation time, improve product’s protection level to IP54, and prolong the service life of the protection components.
Product Details
Oil-filled Transformer S11 11kv/415v 3 Phase 35kv/3.3kv 6.6kv Wooden Case TSTY 1
Oil Cooled Transformer Standard:
GB/T 1094 Power Transformer
GB/T 15164 Oil-immersed Power Transformer Load Guide
GB/T 6451 Three-phase Oil-immersed Power Transformer Technical Parameters and Requirements
GB/T 2536 Transformer Oil
GB/T 311.1 Insulation Coordination of High-voltage Power Transmission and Transformation Equipment
GB/T 10237 Insulation Level of Power Transformer and Air Gap of External Insulation in Insulation Test
DL/T 572 Transformer Operation Regulations

Oil Cooled Transformer Applicable Environment:
1.High ambient temperature: +40℃
2.Low ambient temperature: -25℃
3.Altitude: <1000m. We can also customize according to your demand.
4.Monthly average relative humidity: 90% (20℃)
5.Installation location: Chemical plants, factories, remote places and other harsh environments.
Product Paramenters
Technical Parameter for S11 Series 35kv Three-phase Dual-winding No-load Voltage Regulation Transformer
Rated Capacity (KVA)
Voltage Combination
Connection Group Symbol
No-load Loss R(W)
Load Loss R(W)
No-load Current (%)
Impedance Voltage(%)
L*W*H (mm)
High Voltage(KV)
Tapping Range of High Voltage
Low Voltage (KV)
630
35
±2x2.5% ±5%
3.15 6.3 10.5
Yd11
830
7860
0.65
6.5
2400*1700*2210
800
980
9400
0.65
2500*1850*2390
1000
1150
1150
0.65
2700*1950*2510
1250
1400
1390
0.55
2900*2050*2630
1600
1690
1660
0.45
3050*2130*2750
2000
2170
1830
0.45
3105*2195*2805
2500
2560
1960
0.45
3150*2535*2980
3150
35-38.5
±2x2.5% ±5%
3.15 6.3 10.5
3040
2300
0.45
7
3920*2725*2840
4000
3610
2730
0.45
3310*2915*3070
5000
4320
3130
0.45
3480*3020*3145
6300
5240
3500
0.45
8
3590*2905*3210
8000
35-38.5
±2x2.5%
3.15 3.3 6.3 6.6 10.5
Ynd11
7200
3840
0.35
4070*3050*3595
10000
8700
4530
0.35
4106*2795*3655
12500
1000
5380
0.3
4570*3010*3840
16000
1210
6580
0.3
5235*3295*4615
20000
1440
7950
0.3
5360*3415*4660
25000
1700
9400
0.25
10
5830*3810*4860
31500
2020
112000
0.25
6290*4290*5260
Note: The data in the table is subject to change as required.
